Professional China Pellet Mill Line - LGX560 Biomass Pellet Machine – Shindery Detail:

INTRODUCTION
LGX-560 vertical ring die pellet machine absorbs the quintessence of various pellet machines both at home and abroad, the heart part adopts “double-layer die” as the unique structure. The rollers are made by abrasion-proof alloy steel, this pellet mill with characteristics of unique design, rational structure, lower power consumption, high efficiency, long lifetime. This machine is our initiative patent products in China through meticulous research and development, supplying the gap of vertical feeding ring-die pellet mill at home, reaches the international advanced level. https://www.shindery.com/a-2-lgx560.html
RAW MATERIAL
The equipment is applied to the material with low adhesiveness and low shaping ,such as the rice husk, sunflower seed husk, peanut shell and other fruit shell branch, trunk, bark and other wood waste; a variety of crop straws, rubber, cement ,ash and other chemical materials. The pellet mill is widely used in the feed plant, wood processing, fuel plant, fertilizer plant and chemical plant etc. It is the ideal pressing shaping equipment with low investment and high profit.

SEVEN CHARACTERISTICS
1.Feeding vertically and directly to pelletizing room.
2.Die static, rollers rotating, materials centrifugal, evenly distributed around.
3.Double-layer dies, up and down dual use, high capacity and energy saving.
4.Ring die, vertical structure, conducive to the pelletizing room cooling.
5.Independent output device, ensure formation rate of pellets.
6.Independent lubrication system, bring precise & automatic lubrication to bearings.
7.Feeding system is equipped with inverter which can bring stepless adjustable feeding speed.

Model

LGX560
Power (kw)

Main machine

90

Pellet pusher

1.5

Lubrication pump

0.37
Rotation speed (r/min) 1450
Voltage (v) 380 / customized ,3phase
Pellet size (mm) 4-12
Machine weight ( t ) 5.6
External dimension (mm) 2690*1250*2040
Ring die inner diameter (mm) 560
Capacity (t/h) 1.2-1.5

8d9d4c2f1

How does LGX560 ring die wood pellet machine work?
