COMPREHENSIVE WOOD CRUSHER

Short Description:

SHINDERY comprehensive crusher machine
Usage
comprehensive wood chipper can crush wood log, wood branches, bamboo, building template, stab, wood pallet.
Structure
The comprehensive crusher machine’s feeding mode is adjustable,manual continuous feeding, automatic feeding and retreating.
Control panel with bypass soft starter to bring perfect protection to motor.


Product Detail

Product Tags

SHINDERY comprehensive crusher machine
Usage
comprehensive wood chipper can crush wood log, wood branches, bamboo, building template, stab, wood pallet.
Structure
The comprehensive crusher machine's feeding mode is adjustable,manual continuous feeding, automatic feeding and retreating.
Control panel with bypass soft starter to bring perfect protection to motor.

When the machine is working, first turn on the feeding system in manual mode, and then switch the operating mode to automatic after the feeding system is in normal working. In the automatic state, if the main motor current reaches the upper limit of 240A, the feeding system will stop moving forward, and then the feeding system will backward for 2 seconds, but the main motor is still working. When the main motor current is lower than 150A, the feeding system will continue to work for feeding.

Basically, the machine will not be blocked when it is in automatic operation mode.



1030-650

1330-650

1430-800

Feed conveyor form  chain plate conveyor chain plate conveyor chain plate conveyor
Feed conveyor motor 5.5kw 5.5kw 7.5kw
Chain plate conveyor width  1000mm 1300mm 1400mm
Main machine motor

110

132

160

Outlet system Bottom discharge belt conveyor  Bottom discharge belt conveyor  Bottom discharge belt conveyor
Hydraulic system

132+7.5+5.5

1500*400

11.8

Hydraulic system motor

3kw

3kw

3kw

Electrical control system  Soft start with automatic feeding system  Soft start with automatic feeding system  Soft start with automatic feeding system
Capacity 12t/h 15t/h 20t/h
comprehensive wood pallet crusher
